zapco Reference Series 2 User Manual

55
Reference 1000.4 Specifications
Total Power (14.4V @ 1kHz) Power
Dynamic (4Ω mono)
1200 watts
Rated Power / Channel T.H.D.+N
150 watts x 4 @ 4Ω
< .04%
250 watts x 4 @ 2Ω
< .05%
Bridged to Dual Mono
500 watts x 2 @ 4Ω
< .04%
Frequency Response 20 – 20kHz, + 0 / - .5dB
S/N Ratio > 90dB
Transient Distortion (4Ω, 40W)
< .03%
Slew Rate
> 36 V/µS
Damping Factor
> 300 @ 4Ω
Input Sensitivity
Balanced (DIN) 560mV – 10V
Unbalanced (RCA) 260mV – 5V
Separation > 60dB
Max. Current Requirements 120 Amps @ 1000 watts
Idle Current 1.56 Amps
Dimensions 23”L x 7.5”W x 1.95”H

zapco Reference Series 2 Specifications

General

Brand	zapco
Model	Reference Series 2
Category	Amplifier
Language	English
