Specifications
Output Power
50 watts/ch @ 4Ω, 20Hz-20kHz
80 watts/ch @ 2Ω, 20Hz-20kHz
T.H.D. + Noise
<.05%, 20Hz-20kHz @ 50 watts/ch, 4Ω
<.1%, 20Hz-20kHz @ 80 watts/ch, 2Ω
S/N Ratio >100dB
Dynamic Headroom 1.5dB @ 2 ohm load
Separation >75dB
Damping Factor >300 @ 4 ohms
Input Type Fully isolated RCA
Input Sensitivity 230mV - 2.3 Volts, variable
Maximum Input Level 3.5 Volts R.M.S.
Input Impedance 47K ohms
Power Requirements 25 Amperes max. @ 2 ohms
Fuse Rating Internal, ATO 25 Amperes
Minimum Load 2 ohms stereo - 4 ohms mono
Idle Current .8 Amperes
Dimensions 10 1/4”L x 5 7/8”W x 2 1/4”H
