MAIN CONT V RID = 70%
The Ebrake will be closed with 70% of battery voltage applied to the coil and
then the voltage will be reduced to 49% of battery voltage.
AUX
OUTPUT
STOP
ON
RAMP
A18
OUTPUT
BEHAVIOUR ON A SLOPE
BRAKE
ON
-It drives the coil of a
electromagnetic brake.
-The hydraulic steering function
request is sent to the pump
inverter by the can-bus link.
The truck is electrically hold on a
slope; when the time set by
"auxiliary time" parameter is
elapsed the brake is applied and
the 3-phase bridge is released. Do
not use this combination if the
negative brake is not installed.
BRAKE
OFF
-It drives the coil of a
electromagnetic brake.
-The hydraulic steering function
request is sent to the pump
inverter by the can-bus link.
The truck is not electrically hold on
a slope, but comes down very
slowly; when the time set by
"auxiliary time" parameter is
elapsed, the brake is applied and
the 3-phase bridge is opened. Do
not use this combination if the
negative brake is not installed.
HYDRO
CONT.
ON
-It drives the coil of a hydraulic
steering contactor when the
direction input or brake pedal
input are active or a movement of
the truck is detected.-The
hydraulic steering function
request is also sent to the pump
inverter by the can-bus link.
The truck is electrically hold on a
slope; when the time set by
"auxiliary time" parameter is
elapsed, the truck comes down
very slowly, till the flat is reached.
HYDRO
CONT.
OFF
-It drives the coil of a hydraulic
steering contactor when the
direction input or brake pedal
input are active or a movement of
the truck is detected.
-The hydraulic steering function
request is also sent to the pump
inverter by the can-bus link.
The truck is not electrically hold on
a slope, but comes down very
slowly till the flat is reached.
EXCL.
HYDRO
ON
-It drives the coil of a hydraulic
steering contactor when the
exclusive hydro input is active.
-The hydraulic steering function
request is also sent to the pump
inverter by the can-bus link.
The truck is electrically hold on a
slope; when the time set by
"auxiliary time" parameter is
elapsed, the truck comes down
very slowly, till the flat is reached.
EXCL.
HYDRO
OFF
-It drives the coil of a hydraulic
steering contactor when the
exclusive hydro input is active.
-The hydraulic steering function
request is also sent to the pump
inverter by the can-bus link.
The truck is not electrically hold on
a slope, but comes down very
slowly till the flat is reached.
