Zapi ACE2 User Manual

Page - 46/85 AF2ZP0CL - ACE2 - User Manual
Flow chart showing how to make changes to ADJUSTMENTS Menu.
1) Opening Zapi Menu.
AE2T2B ZP0.12
24V 400A 00000
2) Press Top Left & Right Buttons to enter CONFIG
Menu.
% ' %
' ' '
3) The display will show: SET MODEL.
CONFIG MENU
SET MODEL
4) Press ROLL UP or ROLL DOWN button until
ADJUSTMENTS Menu appears.
% ' '
' ' '
5) ADJUSTMENTS appears on the display.
CONFIG MENU
ADJUSTMENTS
6) Press ENTER to go into the ADJUSTMENTS
Menu.
' % '
' ' '
7) The display will shows SET BATTERY TYPE.
BATTERY TYPE
48V
8) Press ROLL UP or ROLL DOWN button until the
desired parameter is reached.
% ' '
% ' '
9) The desired parameter appears.
TROTTLE 0 ZONE
3%
10) Press SET UP or SET DOWN button to modify
the adjustment.
' ' %
' ' %
TROTTLE 0 ZONE
7%
11) Press OUT.
' ' '
' % '
12) Press ENTER to confirm.
' % '
' ' '
13) Repeat the same from 5 to 12 points for the
other adjustments.
