AF2ZP0CL - ACE2 - User Manual Page - 79/85
Troubleshooting:
- It could be a problem of the contacts in the MC that are not working
(does not pull-in), try replacing the MC.
- If the contactors of MC are working correctly than the problem is in the
controller, replace it.
27) LOGIC FAILURE #2
Cause:
Fault is in the hardware section of the logic board which manages the
phase’s voltage feedback.
Troubleshooting:
This type of fault is not related to external components, so when it happens it
is necessary to replace the ACE2 logic board.
28) CONTACTOR DRIVER
Cause:
The MC coil driver is not able to drive the load. The device itself or its driving
circuit is damaged.
Troubleshooting:
This type of fault is not related to external components; replace the ACE2
logic board.
29) AUX DRIVER OPEN
Cause:
The EB/AUX coil driver is not able to drive the load. The device itself or its
driving circuit is damaged.
Troubleshooting:
This type of fault is not related to external components; replace the ACE2
logic board.
30) ENCODER ERROR
Cause:
This fault is signalled in following conditions: the frequency supplied to the
motor is higher than 40 Hz and the signal feedback from the encoder has a
jump higher than 40 Hz in few tens mSec. This condition is related to a
malfunctioning of the encoder.
Troubleshooting:
- Check both the electric and the mechanical encoder functionality, the
wires crimping.
- Check the encoder mechanical installation, if the encoder slips inside its
compartment raising this alarm condition.
- Also the electromagnetic noise on the sensor bearing can be a cause for
the alarm. In these cases try to replace the encoder.
- If the problem is still present after replacing the encoder, the failure is in
the controller.
31) WRONG RAM MEMORY
Cause:
The algorithm implemented to check the main RAM registers finds a wrong
contents: the register is “dirty”. This alarm inhibit the machine operations.
Troubleshooting:
Try to switch the key off and then on, if the alarm is still present replace the
ACE2 logic board.
