1 GENERAL CHARACTERISTICS
1.1 TECHNICAL SPECIFICATIONS
Motor Types (Traction):.............................................................................. DC SEM
Motor Types (Pump): ............................................................................ DC SERIES
Power ratings (Traction):........................................................................... 1 to 2 kW
Supply Voltage: .........................................................................................24V / 48V
Armature Switching frequency: ..................................................................... 16 kHz
Field Switching frequency: ............................................................................ 800 Hz
Temperature range: ....................................................................... -30 °C to +40 °C
Maximum controller temperature: ................................................................... 75 °C
Version Maximum Traction current Maximum Pump current
200+250 200 A 250 A
300+300 300 A 300 A
400+250 400 A 250 A
1.2 GENERAL DESCRIPTION
ZAPI COMBI SEM-1 controller performs all the electric functions that are usually
presents in transpallet, stacker, low order picker etc.
The controller can perform the following functions:
- Traction controller for SEM motor; full-bridge on the field, half-bridge on the armatu-
re.
- Lifting controller for series excited motors.
- Drivers for ON/OFF electrovalves and for one proportional valve (electrodistributor)
- Interface for serial tiller head
- MDI interface (Multifunction Digital Instrument) battery discharge indicator,
hourmeter, alarms, programmed maintenance.
1.3 MAIN FEATURES
- High frequency MOSFET controller (high efficency, silent, etc.).
- Speed control with regenerative braking (controls the truck also on the slope)
- Idraulic functions control with different programmable speeds and ramps, It is
possible to use proportional functions.
- Lowering speed control through proportional valve.
- All the parameters are programmable by means of the ZAPI console.
- Complete diagnosis through console or MDI.
- High temperature protection with current reduction.
- Drivers real time diagnosis (electro-brake, general contactor and proportional valve.
- Electrobrake and general contactor are controlled with a PWM.
- Drivers protected against short-circuits.
