Zebra 105SL Plus Quick Reference Guide

Load Media
12
P1056467-001 105SLPlus™ Quick Reference Guide 9/28/12
8. If your printer includes a media dancer assembly (1), thread the media under the media
dancer assembly roller. For all printers, thread the media under the media guide roller (
2)
and then the upper media sensor (
3).
9. Push the media forward until it passes under the printhead assembly (1), under the
snap plate (
2), and then over the platen roller (3).
Important • Make sure that you thread the media under these components. If you thread
the media over them, the media obstructs the ribbon sensor and causes a false
RIBBON OUT error.
2
3
1
1
3
2
