Load Media
6
14023L-002 Rev. A 105SL Quick Reference Guide 6/20/07
6. Loosen the thumb screw on the bottom of the outer media guide (not visible from this
angle).
7. Slide the outer media guide all the way out.
8. Thread the media under the lower roller (1) and the upper media sensor (2).
1
2
