Universal Serial
Bus (USB)
The table below provides the contact terminat
-
ing assignments by number and electrical value
for the cable connectors.
Contact Number Signal Name
Typical Wiring
Assignment
1 VBUS Red
2 D- White
3 D+ Green
4 GND Black
Shell Shield Drain Wire
You can refer to the Universal Serial Bus Speci-
fication for details regarding this interface.
28
980348-001 Rev. A
