Front/Cutter Bezel Replacement 980358-303A
Preparations
Open the printer by pulling the release latches forward, then lifting the top cover.
Removal
1. Pry either side free and then lift the bezel
away from the printer.
2. Unplug the connector.
Assembly
1. Align the cutter so that the connector is to
the rear.
2. Plug the connectors together.
3. Align the tabs with the notches in the media
exit and snap the bezel into place.
980358-001 Rev. B 51
