2. Separate and hold open the media hangers (refer to Figure 4).
3. Place the media roll onto the media hangers, ensuring that it is tightly
wound(refertoFigure5).
NOTE:RefertoFigure6.Ifyouareusinglabels,makesurethe
media unwinds from the top of the roll. Tags unwind from the
bottom of the roll.
6
Media
Hanger
Media
Hanger
Figure 4
