ParallelInterfaceRequirements
Therequiredcable(IEEE1284-compliantisrecommended)musthavea
standard36-pinparallelconnectorononeend,whichispluggedintothe
parallelportlocatedonthebackoftheprinter(refertoFigure20).The
otherendoftheparallelinterfacecableconnectstotheprinterconnectorat
thehostcomputer.
Forpinoutinformation,refertopage48.
SerialandParallelCablingRequirements
Datacablesmustbeoffullyshieldedconstructionandfittedwithmetalor
metalizedconnectorshells.Shieldedcablesandconnectorsarerequiredto
preventradiationandreceptionofelectricalnoise.
Tominimizeelectricalnoisepickupinthecable:
n
Keepdatacablesasshortaspossible(6’[1.83m]recommended).
n
Donottightlybundlethedatacableswithpowercords.
n
Donottiethedatacablestopowerwireconduits.
21
Connectsto
ParallelPorton
HostComputer
Parallel
Port
Serial
Port
Connectsto
SerialPorton
HostComputer
Figure20
