PAX4 Series
Print Engine Installation
3/3/11 Wireless Quick Start Guide P1001060-006
Figure 12 • Front View of Print Engine in Applicator (170PAX4)
1
Mounting screws (four total)
2
Keyhole
3
Center mounting bolt (shown inside hole on applicator)
4
Applicator
4
2
1
1
3
1
