Printer Overview
Printer Features
10/26/2010 KR203 Hardware Integrator Guide P1028247-001 Rev. B
Printer Features
Figure 3-3 • Printer Features
Table 3-1 • Printer Features
Printhead Release Bar Cutter Bar
Printhead Platen (drive) Roller
Media Present Sensor Cutter
Control Panel Media Sensors
