Media
Preparing a Media Roll for Use
38
P1028247-001 Rev. B KR203 Hardware Integrator Guide 10/26/2010
Preparing a Media Roll for Use
1. Turn the new media roll as shown below.
2. Tear off a full turn of the media from the roll.
Caution • This is important since the outer end of the paper is usually fixed to the roll with
some type of glue or self-adhesive substance that might otherwise cause paper jam or
even print head damage.
Figure 5-6 • Paper Roll Orientation
Figure 5-7 • Full Turn Paper Removal
Temperature-sensitive
coating
To Next Page
