Accessories
Media Roll Low Sensor
50
P1028247-001 Rev. B KR203 Hardware Integrator Guide 10/26/2010
Media Roll Low Sensor
The media roll low sensor is available in two lengths:
• 01890-300 – KIT PAPER-LOW SENSOR 300MM CBL
• 01890-500 – KIT PAPER-LOW SENSOR 500MM CBL
The sensor alerts the system when a fixed level of media is remaining on the roll.
The media roll low sensor operates by reflecting a light against the white side of a media
roll to detect it. When the media is low, no light is reflected. After three successive media
low conditions are noted by the printer, a media low flag is set. Installing a new roll of
media will reset the flag.
Note • Black marks or dirt on the side of the media roll may signal false media low
conditions.
