Zebra KR403 Specifications

*Specicationssubjecttochangewithoutnotice.
©2010ZIHCorp.E
3
,ElementEnergyEqualizer,ZBI,ZBI2.0andallproductnamesandnumbersareZebratrademarks,andZebra,representationofZebraHeadandZPLareregisteredtrademarksofZIHCorp.Allrights
reserved.UnicodeisatrademarkofUnicode,Inc.GS1DataBarisatrademarkofGS1US,Inc.Windows,WindowsServerandWindowsVistaareeitherregisteredtrademarksortrademarksofMicrosoftCorporationin
theUnitedStatesand/orothercountries.Allothertrademarksarethepropertyoftheirrespectiveowners.
Standard features
Printmethod:direct-thermalreceiptprintingfor•
58mm,60mm,80mm,82.5mmwidthmedia
Loopingpresenterwithpulldetectorandretract•
&retainfunction
Automedialoading•
Horizontalandverticalmountingcapability•
Variousmediamountingoptionsforbehindand•
belowtogiveexibilitytokioskdesign,upto
250mm-diametermediarolls
USBandRS-232serialconnectivity•
203dpiprinting•
Excellentprintqualityachievedthroughprinthead•
alignmentfeaturesandElementEnergyEqualizer™
(E
3
™)forsuperiorprintquality
Windows®driversforplugandplay•
(2000,XP,Vista,Windows7-32&64bit)
21resident1-Dand10resident2-Dbarcodes•
15bitmapfonts,onescalablefont•
Unicode™-compliantwithoneUnicodeWGL4font•
pre-loaded
1.5MBashmemorysupportsawiderangeof•
graphictypes
Maintenancealerts•
Numeroussoftwaretoolsforcommissioning,•
usingandtroubleshootingtheprinter
Printer specifications
Resolution:• 8dotspermm
Max. print width:• 80mm
Max. print length:• 600mm
Print speed:• 152mmpersecond
Media sensors:• Out-of-paper,paperinpresenter,
paperinretractpath,blackmark,inputforexternal
paper-lowsensor
Media characteristics
Max. roll size:• 250mm
Core diameter:• 25mmtypical,12mmwith
optionalaccessories
Media thickness:• 0.054mmto0.11mm
Media types:• Rollorfanfoldpaper
Operating characteristics
Environmental
Operating temp.:• -10°C/14°Fto50°C/122°F
Storage temp.:• -10°C/14°Fto50°C/122°F
Operating humidity:• 10%to95%non-condensing
Storage humidity:• 5%to95%non-condensing
excludingpaper
Electrical:• 24VDC+/-5%averageof2.92Awhen
printing.0.25Awhenidle
Physical characteristics
Embedded
Width:• 107mm/4.2"
Height:• 68mm/2.7"
Depth:• 144mm/5.7"
Weight:• 1.1kg/2.4lb
Fonts/Graphics/Barcode symbologies
Linear barcodes:• Codabar,Code11,Code39,
Code93,Code128,Code128withsubsets
A/B/C,EAN-8,EAN-13,EAN-8andEAN-13with2
or5digitextensions,GS1DataBar(RSS),Industrial
2-of-5,Interleaved2-of-5,Logmars,MSI,MSI-3,
Plessey,Postnet,Standard2-of-5,UCC/EAN-128,
UPC-A,UPC-AandUPC-Ewith
2or5digitextensions,UPC-E
2-Dimensional barcodes:• AztecCode,Codablock,
Code49,DataMatrix,GS1DataBar(RSS)
family(12barcodes),MacroPDF417,MaxiCode,
MicroPDF417,PDF417,QRCode
Graphics:• Supportsuser-downloadedfontsand
graphicsinGRF,PNG,BMPandPCXformats
Fonts:• 15bitmapfonts,onescalablefontandone
UnicodeWGL4font(Western,CentralandEastern
European,Baltic,Cyrillic,Greek,Turkish,Hebrew
andtraditionalArabiccharactersets)
Communication and interface
capabilities
RS-232serialandUSB1.1(2.0-compatible)
Operating system
WindowsXP,WindowsVista,Windows7,
WindowsServer
®
2003,OPOSandLinux™–
RedHatandCaldera
Options and accessories
Media guides:• 58,60,80and82.5mm
Rollholder“universal”variableposition,200mm•
diametermax.
Adaptorforrollholderbelowposition,250mm•
diametermax.
Rollholderwallmount,150mmdiametermax.•
Quick-thubsforeasymountingandremoval•
ofprinter
Paper-lowsensorwith300mmcable•
Adaptorplateandspindleformediaon•
12mmcores
Outputbezelforeasierintegrationand•
intrusionprotection
Outputshuttertoprotecttheprinterfromintrusion•
ordamage
ZBI2.0™–ZebraBasicInterpreterforstand-alone•
andinterfacingintolegacyapplications
64MBexpandedashmemory•
Compactauto-switching70Wpowersupply•
Downloadablefontpacks,Unicodeand•
standardtypes
Specifications at a glance*
www.zebra.com 12604L(03/10)
Thinking about mobilising your workforce?
To find out how your business could benefit from a Zebra mobile-printing solution,
please visit www.zebra.com
The use of mobile printers in a warehouse or supply-chain environment improves productivity and provides a fast return
on investment.
Zebra Technologies – EMEA Headquarters & Sales Office
ZebraTechnologiesEuropeLimited,DukesMeadow,MillboardRoad,BourneEnd,Buckinghamshire,SL85XF,UnitedKingdom
Telephone:+44(0)1628556000 Fax:+44(0)1628556001 E-mail:mseurope@zebra.com Web:www.zebra.com
Other EMEA Locations
Europe:France,Germany,Italy,theNetherlands,Poland,Spain,Sweden Middle East & Africa:Dubai,SouthAfrica

Zebra KR403 Specifications

General

Print Method	Direct thermal
Resolution	203 dpi
Print Width	4.09 inches
Max Print Length	39 inches
Memory	16 MB SDRAM, 8 MB Flash
Connectivity	USB, RS-232 Serial
Media Sensors	Reflective, transmissive
Media Handling	tear-off
Operating Temperature	41°F to 104°F (5°C to 40°C)
