81
Accessories
Large Media Roll Adapter – P1026858
9/24/2010 KR403 Hardware Integrator Guide P1016701-001 Rev. B
Loading Media
1. Open the adapter tensioner assembly by pushing the locking tab .
2. Insert the media through the adapter and into the printer. For narrow media, the printer
will load automatically. For wide media, manual media loading may be required (see
"Manual Media Loading" on page 57).
3. Close and lock the adapter tensioner assembly.
