Zebra LI3678 - Cradle Parts Identification

4 LI3678 Quick Start Guide
Cradle Parts
Figure 1-1 Cradle Front View
Figure 1-2 Cradle Back ViewConnecting the Cradle
Charging/
Communications
Contacts
Pairing
Bar Code
Mounting
Screw Hole
Foot Latch
LED
Mounting
Screw Hole
PAIR
Drain Hole
Canopy Latch
Mounting
Screw Hole
Page Button
Drain Hole
Rubber Feet
Host Cable Guide
Foot Latch Release
Mounting Screw Hole
Mounting Screw Hole
Host Cable Latch
Host Cable (Under Latch)
Rubber Feet
