12 P430i User’s Manual 980470-001 Rev. A
Installation and Setup
Loading a Ribbon
3. Locate the Ribbon Supply Spindle and the Ribbon Take-up Spindle (see above). Load ribbon onto the
supply spindle (under the print head carriage) flange side in, and load the empty core (with tape attached)
onto the take-up spindle. Make sure the ribbon comes off the top of the supply spindle and feeds to the top
of the take-up spindle.
Dual-Sided
Col
or
Ribbon Supply
Spindle
Ribbon Take-up
Spindle
D
u
a
l-S
id
e
d
C
o
lo
r
Flange
Supply Spool
Tak e - up
Spool
