Magnetic Card Stripe Encoder
ISO Standard Encoding
980470-001 Rev. A P430i User’s Manual 49
ISO Standard Encoding
Track #
Field
Separator
Track
Density
Valid
Characters
# of
characters
1 ^ 210 BPI* Alphanumeric
(ASCII 20~95
†)
79
‡
2 = 75 BPI* Numeric
(ASCII 48~62)
40‡
3 = 210 BPI* Numeric
(ASCII 48~62)
107‡
*Bits per inch
†Except the “?” character
‡Including Start, Stop, and LRC characters. Also note that these 3 characters are
automatically managed by the magnetic encoder according to the ISO Standard
Norms.
Note • Refer to the Card Printer Programmer’s Manual for complete programming
information.
