Wireless Congiguration QSG for 802.11n & Bluetooth Radios for Link-OS Mobile Printers
P1048352-001 Rev. C
Setting Printer Connectivity without Certificates
Follow the previously described steps until you get to the Wire-
less Settings screen.
• Enter ESSID as previously instructed.
• When selecting a Security Mode from the dropdown menu
that doesn’t require certificates (e.g. WPA-PEAP as shown),
the Security Username and Security Password fields will
become active.
• Obtain a Security Username and Security Password from your
network administrator and enter in the appropriate field
where shown.
• Click Next to proceed to the Advanced Wireless Settings
window and follow the remaining steps outlined above.
• The Final Stream window displays the applicable Set/Get/Do
commands based on your previous selections.
• Click Next to proceed to the Send Data screen.
SGD
Commands
• Click on Printer to send connectivity configuration commands
to the printer. Otherwise, click on File to save the commands
on your computer.
• Click Finish and the printer will update and reboot.

Zebra QLn220 Specifications

General

Maximum resolution	203 DPI
Display	LCD
Product color	Black, White
RS-232 interface	Yes
Standard interfaces	Serial, USB 2.0, Ethernet
Optional connectivity	Ethernet
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
Flash memory	256 MB
Certification	FCC 15, B, EN55022 B, EN60950, EN55024, VCCI B, EN55024, EN61000-4-2, EN61000-4-3, EN61000-4-4, EN61000-4-5, CE, UL, TUV, CSAMedia
Internal memory	128 MB
Built-in barcodes	1D, 2D, CODABAR (NW-7), EAN128, EAN13, EAN8, Interleaved 2/5, Matrix 2/5, PDF417, POSTNET, UPC-A, UPC-E
Processor frequency	400 MHz
Storage temperature (T-T)	-25 - 65 °C
Operating temperature (T-T)	-4 - 122 °F
Operating relative humidity (H-H)	10 - 90 %
Media thickness	0.0584 - 0.1397 mm
Maximum media length	813 mm
Maximum roll diameter	55.9 mm
Maximum media length (imperial)	32 \

Weight and Dimensions

Depth	173 mm
Width	117 mm
Height	84 mm
