RS5100 Quick Start Guide
12
Charging the RS5100
To Charge the RS5100:
1. Insert the RS5100 into the RS5100 charging slot with the scan window facing the charge contacts.
Figure 8 Insert RS5100 Single Trigger and Double Trigger into Cradle
2. Ensure that the RS5100 is properly seated in the charging slot.
NOTE: It is suggested to charge the RS5100 before doing a firmware update over Bluetooth.
Charging the Spare Battery
1. Insert a spare battery into the spare battery slot.
Figure 9 Insert Battery into Cradle
2. Ensure the battery is seated properly. The Spare Battery Charging LED blinks indicating charging.
MN-003559-02EN_rs5100-qsg-en.fm Page 12
