RS5100 Quick Start Guide
11
RS5100 Scanning with SE4770
To scan a barcode:
1. Launch a scanning application.
2. Press the Scan Trigger and aim the device at the barcode.
3. Adjust the position of the device so that the red laser cross-hair appears at the center of the barcode.
4. The status LED illuminates red. Upon successful decode, the status LED changes from red to green and an
audible beep sounds.
NOTE: In some configurations proper decoding of a barcode is indicated by the software application running on the mobile
computer.
Charging
NOTE: Ensure that you follow the guidelines for battery safety described in the RS5100 Product Reference Guide.
Use one of the accessories in the following table to charge the RS5100 and/or spare battery.
Refer to the RS5100 Product Reference Guide
,
for detailed information on all charging accessories.
Table 1 Charging and Communication
Description Part Number
Charging Communication
Battery
(In Device)
Battery Only
microUSB to
USB
Ethernet
4-Slot RS5100 Charge Only
Cradle
CRD-RS51-4SCHG-01 Yes No No No
20-Slot RS5100 Charge
Only Cradle
CRD-RS51-20SCHG-01 Yes No No No
8-Slot Battery Charger SAC-RS51-8SCHG-01 No Yes No No
40-Slot Battery Charger SAC-RS51-40SCHG-01 No Yes No No
MN-003559-02EN_rs5100-qsg-en.fm Page 11
