Zebra RS5100 - Double Trigger Configuration

RS5100 Quick Start Guide
4
Double Trigger
Figure 2 RS5100 Double Trigger Configuration Features
Imager Window
Battery
Finger Straps
Top Scan Trigger
System LED
System LED
Trigger Assembly
Restore Key
Battery Release Latch
Side Scan Trigger
NFC Icon
Charging Pads for
Cradles
