Unacceptable Label:
• Darkness very low
• Printhead positioned
correctly
• Toggles balanced (equal
pressure on left and right
sides)
Unacceptable Label:
• Darkness properly set
• Printhead too far forward
• “Scratch flowers” on
black area (foggy
appearance): printhead
needs to be moved
rearward
• Walk out wrinkle with
feed button and readjust
• Toggles balanced (equal
pressure on left and right
sides)
Unacceptable Label:
• Darkness properly set
• Printhead way too far
forward
• “Scratch flowers” on
black area (washed out
appearance)
• Printhead needs to be
moved rearward
• Walk out wrinkle with
feed button and readjust
• Toggles balanced (equal
pressure on left and right
sides)
Stripe Maintenance Manual: Volume 1 Troubleshooting
44868L Page 6-7
