Zebra ZXP Series 8 Reference Manual

13
Press the DOWN soft-key until “WIRELESS SETTINGS” is highlighted in reverse video then press
SELECT and the display changes to:
There are several selections hidden. These can be seen by pressing the DOWN soft-key. The
selections are as follows:
Menu Selection Description
RETURN WITHOUT SAVE Exit the current menu, returning to the previous menu.
SAVE SETTINGS Save any setting that have been changed then return to the
previous menu. The printer will then remember these settings after
a power cycle.
RADIO CONTROL
Turn the radio on or off.
SETUP WIZARD Enter the setup wizard, which takes you through the steps to
connect to an access point one step at a time.
DHCP MODE
Enable disable DHCP mode.
SET IP ADDRESS Set the IP Address. Only needed if DHCP is disabled.
SET SUBNET MASK Set the Subnet Mask. Only needed if DHCP is disabled.
SET DEFAULT GATEWAY Set the Default Gateway. Only needed if DHCP is disabled.
SET DEFAULTS
Erase all the wireless settings. If the radio is on, the radio is turned
off. If you want the defaults to be permanent, you will need to also
select “SAVE SETTINGS”.
RETURN
> PRINT TEST CARDS
> NETWORK SETTINGS
> LAMINATOR SETTINGS
> ADVANCED SETTINGS
> WIRELESS SETTINGS
UP DOWN SELECT
RETURN WITHOUT SAVE
SAVE SETTINGS
> RADIO CONTROL
> SETUP WIZARD
> DHCP MODE
> SET IP ADDRESS
UP DOWN SELECT

Zebra ZXP Series 8 Specifications

General

Color	Yes
Maximum resolution	304 x 304 DPI
Standard interfaces	USB 2.0
Connectivity technology	Wired
Weight (imperial)	27.5 lbs
Dimensions (WxDxH)	356 x 519 x 303 mm
Compatible operating systems	Windows XP, Vista, Server 2003
Internal memory	64 MB
Storage temperature (T-T)	23 - 131 °F
Operating temperature (T-T)	15 - 25 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Power requirements	100 - 240 VAC, 50 - 60 Hz

Weight and Dimensions

Weight	12500 g
