Zebra ZXP Series 8 Reference Manual

15
Use the CHANGE soft-key to change the selected digit. Each press of CHANGE increases the
digit value by 1 with a roll-over to zero when necessary. The selected digit will flash. Use the
NEXT soft-key to select the next digit in the sequence. Pressing NEXT when the last digit is
selected will result in the first digit being selected. Press EXIT to save the current IP Address and
exit the menu. Before pressing EXIT, all of the digits on the display must match the desired IP
Address.
Step 3:
Enter the Set Subnet Mask menu by pressing the DOWN soft-key until “SET SUBNET MASK” is
highlighted then press SELECT and the display changes to:
Use the CHANGE soft-key to change the selected digit. Each press of CHANGE increases the
digit value by 1 with a roll-over to zero when necessary. The selected digit will flash. Use the
NEXT soft-key to select the next digit in the sequence. Pressing NEXT when the last digit is
selected will result in the first digit being selected. Press EXIT to save the current Subnet Mask
and exit the menu. Before pressing EXIT, all of the digits on the display must match the desired
Subnet Mask.
Step 4:
Enter the Set Default Gateway menu by pressing the DOWN soft-key until “SET DEFAULT
GATEWAY” is highlighted then press SELECT and the display changes to:
IP: 000.000.000.000
CHANGE NEXT EXIT
Mask: 000.000.000.000
CHANGE NEXT EXIT

Zebra ZXP Series 8 Specifications

General

Color	Yes
Maximum resolution	304 x 304 DPI
Standard interfaces	USB 2.0
Connectivity technology	Wired
Weight (imperial)	27.5 lbs
Dimensions (WxDxH)	356 x 519 x 303 mm
Compatible operating systems	Windows XP, Vista, Server 2003
Internal memory	64 MB
Storage temperature (T-T)	23 - 131 °F
Operating temperature (T-T)	15 - 25 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Power requirements	100 - 240 VAC, 50 - 60 Hz

Weight and Dimensions

Weight	12500 g
