1: Introduction
Laminator Components
P1045430-002 Zebra ZXP Series 8 Card Printer User’s Manual 3
Laminator Components
The following figure shows components of the Laminator.
Heater
Upper Laminate Cassette
(single-sided and dual-sided laminators)
Lower Laminate Cassette
(dual-sided laminator only)
Lower Laminate Cassette Latch
(dual-sided laminator only)
Upper Laminate Cassette Latch
(single-sided and dual-sided laminators)
Output
Hopper
Manual Advance Tool
Enclosure
Lock
(optional)
