zebris JMAOptic - JMA-Optic Face Bow

The transport switch (11) disables the batteries to prevent
accidental activation of the head bow and discharge of the batteries.
Cleanliness/integrity of the optical components (1 & 3) must
be checked before each use to ensure the accuracy of the
measuring system.
Seite 15/69
Page 15/47JMA-Optic
3.4. JMA-Optic Face Bow
1 B 2
A
4
3
5
6
7
8
9
10
C
C
11
