Device contains lithium-ion batteries. When shipping the device, comply
with the transport instructions for Li-Ion batteries. In addition, a labeling
of the transport packaging according to valid regulations is required.
The batteries in the face bow can only be replaced by trained service
technicians.
Therefore it is required to sent the device to the manufacturer.
Never attempt to open the face bow or replace the batteries yourself,
as this may affect the measurement accuracy and may result in an
electric shock.
Seite 16/69
Page 16/47JMA-Optic
3.4.1. Technical data
Property Value
Dimensions (W x H x L) 222 x 60 x 250 mm
Weight 208 g
Power supply 5V DC / 2.5W (USB for battery charging)
Max. recording rate 60 Hz
Measuring accuracy (occlusal) ± 0.05 mm (x, y, z); ROM 15 mm
Connector socket device specifi c Push-Pull plug (USB)
PC interface WLAN / USB
3.4.2. Type plate JMA-Optic Face Bow
