15
automatic shutdown, the oscilloscope will automatically shut down 15 minutes after
no key operation.
2. You can choose whether to turn on sound or not.
3. Choice of language: Chinese or English.
4. Keep this menu open, and long press "s" to switch the background color of
the measurement item.
Parameters
Model DSO3D12 Coupling AC/DC
Channels 2 AUTO Support
Screen size 3.2inch Measurement 14 types
Sampling rate 250Msa/s Precision of V ±2%
Bandwidth 120M XY mode Support
Equivalent sample 500M Screenshot Support
Rise time <3ns Frequency ±0.01%
Storage depth 64K Single Support
Impedance 1MΩ FFT Support
Time base 5ns – 10s Wave out amp 2.5V±0.05
Ver sensitivity 10mV/div-10V/div Wave out freq 5MHz(sin) 1MHz(other)
Max voltae ±40V（x1）
±400V（x10）
Shell size width*hight* thickness
145*86*33mm
Trigger mode Auto/Normal Language CN/EN
Trigger type rise/fall Charger TYPE-C / 5V
Display mode YT / Roll Charge current 700mA
Persistence None/1s / ∞ Weight 266g
Multimeter parameters
Function Range precision
DC Voltage 600mV/6.00V/60.0V/600V/750 ±(0.5%+3)
AC Voltage 600mV/6.00V/60.0V/600V ±(1%+3)
DC Current 600mA / 10A ±(2%+5)
AC Current 600mA / 10A
±(3%+5)
