17
channel two on off Turn on/off CH2
T B second It is equivalent to pressing the “s” key once
nano second It is equivalent to pressing the “ns” key once
M V one It is equivalent to pressing the “mV(ch1)” key once
V one It is equivalent to pressing the “V(ch1)” key once
M V two It is equivalent to pressing the “mV(ch2)” key once
V two It is equivalent to pressing the “V(ch2)” key once
Test resistance Multimeter, measuring “Resistance”
test continuity Multimeter, measuring “Continuity”
test D C voltage Multimeter, measuring “DC Voltage”
Multimeter diode Multimeter, measuring “Diode”
Multimeter
Capacitance
Multimeter, measuring “Capacitance”
Multimeter A C
voltage
Multimeter, measuring “AC Voltage”
Turn off power Shutdown
Q & A
0. I am a beginner, how do I reset the device to its initial state?
Answer: Open Menu->Set, and then long press the "Auto" button to reset.
1. What is the difference between probe 1X and 10X?
Answer: The 1X does not attenuate the signal, and the 10X attenuates the signal
amplitude by 10 times. When the measuring voltage is higher than 40V, 10X is used.
In addition, the bandwidth of 1X file can only reach about 5M. So generally we
usually use 10X, and use 1X when the measured signal amplitude is less than a few
hundred millivolts. Note: If the probe test lead is set to 10X, it must be set to 10X in
the menu. 1X is the same. That is to keep the two consistent! !
2.When the timeBase is >50ms, the waveform refresh becomes slower?
Answer: The time base of 50ms means the time of "one grid". There are 12 grids in
the horizontal direction. The time to perform one sampling=50*12=600ms, so it is
normal for the waveform refresh to be slow.
3.How to measure DC power voltage?
