9
000000Ć1150Ć839 IOLMaster 11.02.2004
1 Joystick with release button
for adjusting the instrument horizontally (X, Y) and vertically (Z, by
turning)
2 Display
3 Reds marks
indicates patient's eye level for optical alignment
4 Forehead rest
5 Connector board
6 Display connector
7 Device control connector
8 Mouse connector
9 Keyboard connector
10 Left mouse button
11 Right mouse button
12 Touchpad for cursor movement
13 Chin rest
14 Holding pins for paper pads
also used for test eye alignment
15 Patient alignment knob
16 3,5" disk drive
for technical service only
17 Identification label
18 Instrument lock knob
Optionally available accessories
q Footswitch
q Printer for result printout
q Keyboard support
q Instrument table IT 3L
q Software, Option A
q Software, Option B
q Power isolation transformer
Instrument description
