NOTES ON DEVICE SAFETY LSM 710 and LSM 780
Carl Zeiss Physical Dimensions Systems
8 M60-1-0025 e 02/2010
1.4 Physical Dimensions
Length (cm) Width (cm) Height (cm) Weight (kg)
Small passively damped system table
90 75 77 80
Small actively damped system table
90 75 77 90
Large actively damped system table
120 90 77 120
Active anti-vibration table (NLO)
for Mai Tai Laser or Chameleon
180 150 75 200
Active anti-vibration table (NLO)
for two-microscope configuration
250 150 75 400
Scanning Module LSM 710, LSM 780
50 45 22 27
Scanning Module LSM DuoScan
40 15 13 8
Module ConfoCor 3
49 27 18 25
Microscope
50 35 50 20
Electronic Rack with laser units 710
80 60 65 80
Plug-in unit external laser
70 55 25 10
Electronic Rack 7 LIVE / 7 DUO
70 60 65 20
Laser Module LIVE
66 52 22 58
Laser Rack In Tune
80 60 45 40
