7
Pull the plug and cord (3) out of the vacuum cleaner. Do it
smoothly (do not tug) to avoid cord tangling and blocking in
the vacuum body.
Whilepulingoutthecordpayattentiontothe
yellowstripewhichsignalstheendofthecord.
Furtherattempts(pullingoncord)mayresultin
damagingthecord.
8
Plug in the appliance.
Before operation make sure that the SAFBAG bag is installed
in the vacuum cleaner chamber and that inlet lter and the
HEPA outlet lter is installed in the appliance.
9
Switch on the vacuum cleaner by pressing the “on/off”
button (8).
10
The vacuum cleaner is equipped with electronic power
regulator allowing a stepless regulation of vacuum cleaner
power. The power regulation is performed with a slider.
Moving the slider right or left will increase or reduce
the suction power.
The following slider positions are recommended:
– for delicate fabrics such as curtains, etc.
– for upholstered furniture
– for carpets and oor coverings
– for hard surfaces such as oor, tiles,
parquet etc.
The power may also be adjusted individually depending on
the type of surface, vacuum effectiveness and suction power
of the switchable combination brush.
11
The vacuum cleaner is equipped with the “Parksystem
Auto-Start” function (available only in models VC1006.0HT,
VC1006.0ST and VC1006.0HP). It allows to switch the
appliance for a short time using the fastening hook of
the combination brush, without having to use the on/off
button. To do so, while the vacuum cleaner is in operation
insert the fastening hook of the combination brush to the
combination brush fastener (2) (the vacuum cleaner must be
in a horizontal position). The vacuum cleaner will be switched
off automatically.
12
The vacuum cleaner is also equipped with a mechanical
suction power regulator (11) located on the suction hose
handle. It can be used to adjust the suction power slightly for
a short time without having to use the slider (6).
Filter disassembly
Before changing the lters make sure that the vacuum cleaner
is switched off and unplugged from the mains supply.
INLET FILTER
1
Release the catch of front cover (10) and open it.
2
Remove the SAFBAG dust bag module from the vacuum
cleaner chamber.
C
3
Put out the cover of inlet lter together with installed inlet
lter from the guide rails located on back wall of vacuum
cleaner chamber.
4
Take out the inlet lter from the inlet lter cover.
5
Put the new lter into inlet lter cover (17). Pay attention
whether the edges of lter cling closely to the cover of lter.
6
The cover of inlet lter (17) together with installed lter
press home into guide rails to the previous location.
The damaged inlet lter should be replaced
with a new, genuine manufactured product
only.
7
Insert the SAFBAG dust bag module to the vacuum
cleaner chamber.
8
Close the cover by pressing it until you hear
a characteristic click – pay attention not to trap the dust bag.
HEPA OUTLET FILTER
The vacuum cleaners are equipped with a H11/H13 class
HEPA outlet lters.
HEPA lters are high-quality lters produced from special
bres which are able to stop almost all dust particles.
The H11/H13 class indicates the permeability of the lter.
The H11 HEPA lter stops 95% of particles as small as 0.3
micron, and the H13 HEPA lter stops as much as 99.95%
of all impurities.
1
In order to replace the HEPA lter, press the blocking
mechanism of the outlet lter cover and slide up the cover of
the vacuum cleaner.
2
Remove the HEPA lter cassette and replace it with
a new one. The HEPA lter assures circa 1 year of effective
usage.
3
Slide the outlet lter cover back on in such a way that the
fastenings on the side of the cover t into the sliders in the
vacuum cleaner housing. The lter cover fastening should
close.
SAFBAG dust bag disassembly/assembly
E
1
The vacuum cleaner is equipped with safety valve located
in chamber of dust container (bag). It opens automatically
in case of total stopping of suction hose or total stopping of
equipment elements connected thereto, as well as in case
of overll of dust bag. After opening the valve one can hear
characteristic “whirr” sound inside the vacuum cleaner.
2
When the “Dust bag full” indicator light (7) comes on
when the nozzle or brush is above the oor, it indicates that
the bag needs to be replaced. The “Dust bag full” indicator
light may come on when the suction hose or connected
accessories become clogged.
3
Switch off the vacuum cleaner by pressing the on/off
button (8) and unplug the appliance.
4
Press the two side buttons on the end of the hose and
remove the hose end from the inlet opening of the vacuum
cleaner.
D
