Zenair CH2000 - Replacement of Rudder; Replacement of Stabilator

ZENAIR CH2000 SERVICE MANUAL
________________________________________________________________________
STRUCTURE (cont’d).
REPLACEMENT OF RUDDER - Fig. 8
REMOVAL
1. Disconnect the two control cables from the rudder horn.
2. Disconnect the grounding cable and the tail light wiring.
3. Remove the lower hinge bolt.
4. Remove the upper hinge bolt and remove the rudder.
Caution: Do not lose the hinge bushings.
REINSTALL the rudder in reverse order of removal. Check all bolts for safety.
REPLACEMENT OF STABILATOR - Fig. 8
REMOVAL
1. Remove the rudder.
2. Remove the side panels. (See (1) Fig. 8)
3. Remove the gap filler (See (2) Fig. 8)
4. Remove the bolt at trim actuator and fork. (See (3) Fig. 8)
5. Disconnect the electric wiring if aircraft equipped with electric trim.
6. Remove the upper and lower trim actuator support screws and remove the trim
actuator assembly.
7. Disconnect the grounding cable.
8. Disconnect the control cables from the horn.
Note: Attach the cables to the fuselage for easy reinstallation.
9. Remove the right and left hinge bolts and remove the complete stabilator.
Caution: Do not lose the hinge bushings.
REINSTALL the stabilator in reverse order of removal.
4.4 Oct-00
