78 Rev.C
www.zenec.com
EU Legal Representative: ACR S & V GmbH · Industriestraße 35 · D-79787 Lauchringen · Germany
ZENEC by ACR AG · Bohrturmweg 1 · CH-5330 Bad Zurzach · Switzerland
Hereby, ACR Brändli + Vögeli AG declares that the type of radio equipment ZENEC Z-E2055 complies
with the 2014/53/EU Directive. The full text of the EU Declaration of Conformity is available at the following
Internet address: http://www.zenec.com (see link "Product Conformity Documents" in the footer area of the
page).
Z-N528: E9 10R-05 16981
10R-05 16981
9
A10 A12 A14 A16A2 A4 A6 A8
A9 A11 A13 A15A1 A3 A5 A7
B1 N.A.
B2 N.A.
B3 KL 30 / Constant +12V PWR
B4 N.A.
B5 Illumination
B6 Switched +12V antenna PWR
B7 KL 31 / Power GND
B8 KL 15 / Switched +12V PWR
A9 S
A10 S
A11 S
A12 S
A13 S
A14 S
A15 S
A16 S
A1 KL 31 / Power GND
A2 KL 30 / Constant +12V PWR
A3 KL 15 / Switched +12V PWR
A4 Illumination
A5 Switched +12V amplifier PWR*
A6 Parking
A7 Switched +12V antenna PWR
A8 Reverse
B2
B1
B4
B3
B6
B5
B8
B7
B9
B10
B11
B12
B13
B14
B15
B16
ISO CONNECTORS
(HARNESS)
12V DC / 15 A
NEGATIVE
DAB ANTENNA IN:
SWITCHED 12V SUPPLY
