SR23 - 923-03509 4-1 CS - PARTS
MODEL PARTS
SECTION 4
MODEL PARTS
All CS models are module level repair only. Parts
contact information is below.
Voice: 1-888-3-ZENITH
Fax: 1-888-6-ZENITH
Mail: ZENITH NATIONAL PARTS
P O Box 240007
Huntsville, AL 35824-6407
MODEL PARTS
H27E46DT
Item Description
009-02097 Module, Video Output
014-12254-P12 Cabinet Rear
014-12336-P05 Cabinet Front
020-04330-P62 Coil, Degausser
030-01532-01 Decorative Item, Logo, Zenith
050-02361-01 Connector and Cable Assembly, 35V CTV Yoke
124-00233-04 Space Command Transmitter, MBR3447C
192-00916 Lens, IR
206-03755 Instr Book, Operation & Installation
A-18299-04 Line Cord and Terminals Assembly,
A-18378-01 CRT Assembly w/Deflection Yoke and Bender
A-18695-P24 Gnd Strap Ass’y, CRT
A-18793 Accessory Kit, Cables and Software, Video
Mirror/Audio
A-19129 PC Board Ass’y, VGA Card
F-53646 Keyboard Ass’y, 10 Key with Tall IR
P009-02197 Module, Large Signal
P009-02295-01 Module, Small Signal
P049-01368-08 Speaker, Oval, 6 X 13 cm
P050-02864-07 Connector & Cable Assembly, Speaker
Interconnect
PF-54515 Front Jack Ass’y with Cables
H27E46DT8
Item Description
009-02097 Module, Video Output
014-12254-P12 Cabinet Rear
014-12336-P05 Cabinet Front
020-04330-P62 Coil, Degausser
030-01532-01 Decorative Item, Logo, Zenith
050-02361-01 Connector and Cable Assembly, 35V CTV Yoke
124-00233-04 Space Command Transmitter, MBR3447C
192-00916 Lens, IR
206-03755 Instr Book, Operation & Installation
A-18299-04 Line Cord and Terminals Assembly
A-18378-P03 CRT Assembly w/Deflection Yoke (2H) A, 27V
1.4R (Foshan)
A-18695-P24 Gnd Strap Ass’y, CRT
A-18793 Accessory Kit, Cables and Software, Video
Mirror/Audio
A-19129 PC Board Ass’y, VGA Card
F-53646 Keyboard Ass’y, 10 Key with Tall IR
P009-02197 Module, Large Signal
P009-02295-01 Module, Small Signal
P049-01368-08 Speaker, Oval, 6 X 13 cm
P050-02864-07 Connector & Cable, Assembly, Speaker
Interconnect
P149-00706 Magnet, Purity Correction, ‘Chevron Magnet’
PA-19410 Convergence Helper
PF-54515 Front Jack Ass’y with Cables
H32E46DT
Item Description
009-02097-01 Module, Video Output
014-12284-P33 Cabinet Front
014-12285-P10 Cabinet Rear
020-04330-33 Coil, Degausser
030-01532-01 Decorative Item, Logo, Zenith
124-00233-04 Space Command Transmitter, MBR3447C
152-00335-01 Wedge, CRT Spacer
192-00916 Lens, IR
206-03755 Instr Book, Operation & Installation
A-18299-04 Line Cord
A-18695-03 Gnd Strap Ass’y, CRT
A-18793 Accessory Kit, Cables and Software, Video
Mirror/Audio
A-19111 CRT Assembly w/Deflection Yoke and Bender
A-19129 PC Board Ass’y, VGA Card
F-53707 Keyboard Ass’y, 10 Key, with Short IR
P009-02198 Module, Large Signal
P009-02295-02 Module, Small Signal
P049-01368-08 Speaker, Oval, 6 X 13 cm
P050-02864-06 Connector & Cable, Assembly, Speaker
Interconnect
PA-19298-02 PC Board Ass’y, Daughter
PA-19410 Convergence Helper
PF-54515 Front Jack Ass’y with Cables
H36E46DT
Item Description
009-02098 Module, Video Output
014-12269-P18 Cabinet Front
014-12270-P16 Cabinet Rear
020-04330-34 Coil, Degausser
030-01532-01 Decorative Item, Logo, Zenith
050-02361-03 Connector and Cable Assembly, 35V CTV Yoke
124-00233-04 Space Command Transmitter, MBR3447C
192-00916 Lens, IR
206-03755 Instr Book, Operation & Installation
A-18299-04 Line Cord
A-18695-04 Gnd Strap Ass’y, CRT
A-18793 Accessory Kit, Cables and Software, Video
Mirror/Audio
A-19110 CRT Assembly w/Deflection Yoke and Bender
A-19129 PC Board Ass’y, VGA Card
F-53707 Keyboard Ass’y, 10 Key, with Short IR
P009-02199 Module, Large Signal
P009-02295-03 Module, Small Signal
P049-01368-08 Speaker, Oval, 6 X 13 cm
P050-02864-06 Connector & Cable, Assembly, Speaker
Interconnect
PA-19298-03 PC Board Ass’y, Daughter
PA-19410 Convergence Helper
PF-54515 Front Jack Ass’y with Cables
