Zephyr Pyramid User Manual

18
Pyramid Use, Care, and Installation Guide
PYRAMID
UNDERCABINET
CORE
Removing the Filters (FIG. E):
1. Pull down PAS panel (shaded in gray).
2. Push in on filter handles.
3. Pivot front of filter downward.
4. Remove filter by pulling away from hood.
Maintenance
FIG. E
LumiLight LED
In the unlikely event that your LumiLight LED fails,
please contact Zephyr to order replacement parts.
See the list of parts and accessories page for part
numbers and contact information.
LED Removal (FIG. F):
1. Remove entire PAS panel by (4) screws and
remove filters.
2. Remove the side panels by (2) screws each and
remove the light panel by (2) screws.
3. Disconnect LED light quick connector.
4. Push in the two side clips on the ends of the
LED light.
5. Push LED light through the light panel opening.
Push the clip
FIG. F

Zephyr Pyramid Specifications

General

Brand	Zephyr
Model	Pyramid
Category	Ventilation Hood
Language	English
