General Maintenance
6.29
ABS 12 Volt Fuse
The ABS 12 volt fuse is located underneath the seat.
The ABS fuse holder (see arrow) is plugged into a protective red
cap. To release the fuse holder from the red cap, gently pull the
tab away from the cap and lift fuse holder.
To access the 12 volt ABS fuse:
1. Remove two bolts securing the seat to the motorcycle frame.
Refer to Component Fasteners, see page 6.6.
2. Pull the seat rearward to gain access to the fuse.
3. Gently pull the tab (A) away from the red cap to release the
fuse holder and pull upwards.
4. Replace the fuse.
The 12-volt fuse value is listed below:
FUSE RATING CIRCUITS CONTROLLED
0 25A ABS-18 Motor
