Controls and Components
3.5
A. Headlight
• For headlight operation, see “Handlebar Controls”, on
page 3.17.
• For headlight bulb replacement, see “Headlight Bulb
Replacement”, on page 6.22.
• For headlight alignment, see“Headlight Alignment”, on
page 6.21.
B. Front Turn Signal
• For turn signal operation, see “Handlebar Controls”, on
page 3.17.
• For turn signal light bulb replacement, see “Turn Signal
Light Bulb Replacement”, on page 6.24.
C. AC Charger Power Connection
For description and operation, see “Power Pack”, on
page 5.1.
D. Brake/Tail Light
For brake/tail light bulb replacement, see “Brake/Tail LED
Replacement”, on page 6.24.
E. Rear Turn Signal
• For turn signal operation, see “Handlebar Controls”, on
page 3.17.
• For turn signal light bulb replacement, see “Turn Signal
Light Bulb Replacement”, on page 6.24.
F. Kickstand
The kickstand swings out from the side and supports the
motorcycle when parked. The key switch should be in the
OFF position when parked.
G. Kickstand Switch
This switch is a safety feature that prevents motor operation
when the kickstand is down. If the kickstand were down
when riding it could contact the ground causing you to lose
control of the motorcycle and cause personal injury.
CAUTION: Park only on a flat firm surface, otherwise the
motorcycle could fall over causing damage.
H. Integrated Power Pack Charger
For description and operation, see “Power Pack”, on
page 5.1.
