Troubleshooting
7.9
Battery Management System
The Battery Management System (BMS) is located inside
the power pack. On motorcycles equipped with ZF3.6
modular power packs, a window (A) on the side of the
power pack provides a visual notification about the status
of the power pack.
There are four LED lamps that will flash: one red and three
green lamps. The window is located on the front side of the
power pack. Refer to the following pages to understand the
meaning of the BMS flash code patterns.
Note: The other circular cover is for diagnostics only.
Zero Owner's Manual (FX and FXS).book Page 9 Tuesday, October 23, 2018 1:54 PM
