A Menu/Return button. Press to access menu or
return to the previous panel.
A Confirm button. Press this button to confirm in the
menu operation.
Monitor Harness Connector
Indicates that the camera and screen are not paired
Indicates that current signal strength, and that the
camera and screen are paired
NOTE:
(1) (1) In split screen mode, the menu panel cannot be accessed, please
press CH- to switch to single screen first.
(2) CH- : Monitor Channel Selection Button. Repeated presses of this
button cycle through each camera channel one by one, and dual camera
channels on the screen. These single and multiple display options provide
the user with great viewing flexibility.
Before installing the cameras, it is important to decide which cameras
will be paired to which channel numbers so that when the channel
selections are made, the screen will display the ideal grouping of channels.
(If you need to renumber the cameras, you can re-pair them, Pairing Step
refer to 4.2.1)
4 SYSTEM OPERATION
The following graphic illustrates the layout of the software management
system (SMS) panels and their associated sub-panels. Please note that
you can press the buttons of monitor to access or modify the SMS panels.
4.1 Menu Description
There are 4 primary menu selections.
To Next Page
