Zetor Proxima 80 2012

To Next Page

To Previous Page

186

MAIN TECHNICAL PARAMETERS

TECHNICAL DATA OF ENGINES OF TRACTORS PROXIMA (TIER II)

Engine model 7204 1104 1204 1004

Injection pump type PP4M10P1f 3420 PP4M10P1f 3419 PP4M10P1f 3423 PP4M10P1i 3735

Nozzle type DOP 150S 423-

4128

DOP 150S 425-

4133

DOP 150S 425-

4133

DOP 150 S 428 -

4104

Injector opening pressure MPa 22-0,8

Timing angle ° 11 11 12 9

Valve clearance measured

at cold engine

- suction

- exhaust

0,25±0,05
