45
ACQUAINTANCE WITH TRACTOR
C172 C173
∗ REVERSOR SHIFTING LEVER
F -
Forward drive; lever in forward
position
R -
Backward drive; lever in back-
ward position
The reversor lever has no neutral
position. Therefore neutral must
be shifted by the main shifting
lever for stopping the tractor.
PARKING BRAKE LEVER, PTO SHAFT
CONTROL LEVER AND PICK UP HITCH
CONTROL LEVER
1. Control lever of PTO shaft clutch
2. Parking brake lever
3. Pick up hitch control lever
