Zetor Proxima 80 2012

194
MAIN TECHNICAL PARAMETERS
FORCES
Proxima
Type of engine 70 80 90 100
Lift capacity at the end of the lower drawbars of the rear thee-
point hitch during the entire lift while using up the maximum
pressure with 2 outer cylinders
- cylinder 63mm in diameter (kN)
- *cylinder 75mm in diameter (kN)
27
38
Lift capacity at the end of the lower drawbars of the front three-
point hitch during the entire lift while using up the maximum
pressure (kN) 23
POWER
Power on output shaft (kW±2%)
- at nominal speed engine and shifted speed 1,000 rpm of the
output shaft
New engine having 100 Mh max. 38.5 45.5 52 58
Run-in engine (over 100 Mh 40.5 48 54.5 60.5
