Changing the transmission oil
1 - Maximum Level
2 - Minimum Level
Remove the drain plug from the bottom of the
transmission and drain the oil.
Return the drain plug and check for tightening and
leakage.
U18N075
1 - Transmission oil drain Plug
U18N076
1 - Dipstick
2 - Filler
Fill the transmission with new oil not exceeding the
maximum level marked on the dipstick.
z Capacity 35 l (9.24 US Gal)
U18N077
Important: Always use the same type of oil. Using another type of oil or oil with different
specifications may damage the transmission. Dispose of the old oil according to valid legal
regulations.
