Connecting and disconnecting implement
Caution: Do not attach a PTO shaft while the engine is running and ensure all safety shields
are in place.
Caution: Be especially careful when working with an aggregated implement near other people
or vehicles. Take into account the overall width of the unit to prevent traffic accidents.
If the PTO is used, remove the cover (1) from the PTO
shaft.
Connect the lower left link, then connect the lower right
link using the adjusting handle, if necessary.
Connect the upper link.
Connect the PTO shaft to the tractor and make sure it is
properly locked in place.
Adjust the stabilizer bars so that it corresponds to the
implement and tighten the retaining nuts.
To disconnect the implement, proceed in the reverse
order.
U18N048
CONTROLS, INSTRUMENTS & OPERATIONS
