Volumes of liquids
(L)
Fuel tank volume 60 60
Cooling system 8.5 8.5
Crankcase (with filter) (L) 6.7 6.7
Transmission and hydraulic system 3.5 3.5
Front axle housing 10 10
Dimensions
Total length with three-point hitch mm 3,590 3,590
Total width (mm) 1,620 1,620
Total height (mm) 2,530 2,530
Total maximum permissible width according to the used rear
tires mm (in.)
320-70 R24
1620
(64)
1620
(64)
17,5L-24
1870
(74)
1870
(74)
Wheelbase (mm) 1,935 1,935
Ground clearance (mm) 350 350
Min. turning radius without brakes (mm) 3,820 3,820
Weight with ROPS or cab 1,900 1,900
MAIN TECHNICAL PARAMETERS
